Store Job
Saves the current job A job is a user-configured program in In-Sight EasyBuilder consisting of functions and designed for specific applications. You can create and edit jobs using the In-Sight EasyBuilder interface, and load them on a vision system for deployment in a live environment. into the specified slot in flash memory on the In-Sight vision system.
- To use the job ID number, the job must be saved with a numerical prefix of 0 to 999.
Store Job Inputs
Syntax: TJ<ID><Name>
| Parameter | Description |
|---|---|
| ID | The job ID number (0 to 999). |
| Name | The name of the job. The command will execute with or without the .JOBX file extension. |
Store Job Outputs
Returns a status code, followed by a line terminator. The status codes are:
| Status Codes | Description |
|---|---|
| 1 |
The command was executed successfully. |
| 0 |
Unrecognized command. |
| -1 |
The job ID number is invalid or it is not an integer. |
| -6 |
User does not have Full Access to execute the command. |
Store Job Example
To name the current job Test and save it into slot 0 on the In-Sight vision system, issue the following command: TJ00Test.jobx
The In-Sight vision system responds with 1, indicating that the current job was successfully saved.
