Snippet for Command Sender to Emulator
Snippet for Command Sender to Emulator - VGRCommandSender.cxd:
The snippet for Command Sender to Emulator is for sending commands to Emulator including automatic initial setup.
If DataMatrix is in the top left corner, it is read at the time of image loading and the decoded string (VGR command is encoded) is sent to the job on Emulator through TCP/IP.
When the DataMatrix on the next image is the same as the previous one, the command is not sent out. Use the Send DM Command button to send the command.
Note: Make sure the port number is the same as you use in TCPDevice function on a spreadsheet job.
|
|
|
|---|---|
| Number | Definition |
| 1 | To send the command in the EditString below, push the Send Command button. |
| 2 |
To send the command in the below box, push the Send DM Command button. |
| 3 | Decoded code from DataMatrix on an image |
| 4 | The password to log into the Emulator |
| 5 |
The user name to log into the Emulator |
| 6 | The port numberfor TCP/IP assigned in TCPDevice on the job to communicate with VGRProcessCommand |
