Laser Compliance
WARNING: Laser light, do not stare into beam: Class 2M laser product. Failure to follow these instructions may cause serious injury.
Cognex places the following labels on every 3D-L4000 series vision system:
Complies with FDA performance standards for laser products except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019.
WARNING: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
| Specification | 3D-L4050 | 3D-L4100 | 3D-L4300 |
|---|---|---|---|
| Wavelength | 450 nm +/- 10 nm | ||
| ½ Angle Beam Divergence | W0 1.54 | W0 0.93 | W0 0.80 |
| Pulse Duration | Varies to DC | ||
| Maximum Power | <5mW accessible power | ||
