Laser Compliance
WARNING: Laser light, do not stare into beam: Class 2 and Class 2M laser products. Failure to follow these instructions may cause serious injury.
Cognex places the following labels on every L38 series vision system:
-
Blue laser:
-
Red laser:
Cognex places the following labels on every L38-500 vision system:
-
Blue laser:
-
Red laser:
Complies with FDA performance standards for laser products except for conformance with IEC 60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019.
WARNING: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
| Blue Laser Specification | L38-33 | L38-50 | L38-100 | L38-300 | L38-500 |
|---|---|---|---|---|---|
| Wavelength | 445 nm +/- 10 nm | ||||
| ½ Angle Beam Divergence along Y-Axis(mrad) | W0 2.40 | W0 1.54 | W0 0.93 | W0 0.80 | W0 0.50 |
| Beam Divergence along X-Axis | 32° | 32° | 32° | 32° | 40° |
| Pulse Duration | Varies to DC | ||||
| Maximum Power | < 5 mW accessible power | < 30 mW | |||
| Red Laser Specification | L38-33 | L38-50 | L38-100 | L38-300 | L38-500 |
|---|---|---|---|---|---|
| Wavelength | 638 nm +/- 10 nm | ||||
| ½ Angle Beam Divergence along Y-Axis (mrad) | W0 2.40 | W0 1.54 | W0 0.93 | W0 0.80 | W0 0.50 |
| Beam Divergence along X-Axis | 32° | 32° | 32° | 32° | 40° |
| Pulse Duration | Varies to DC | ||||
| Maximum Power | < 5 mW accessible power | < 30 mW | |||
