USB Connection
| Codes | Settings and Supported Devices | Codes |
|---|---|---|
|
|
*USB-COM/RS-232 (Not supported on DM8700)
DM50 ● DM60 ● DM70 ● DM150 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
USB Keyboard (Not supported on DM8072)
DM50 ● DM60 ● DM70 ● DM150 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable USB Keyboard for the base station
Reboot needed for enabling USB keyboard for the base station!
DM8000Base (IBASE) |
|
|
*Disable USB Keyboard for the base station
Reboot needed after disabling USB keyboard for the base station!
DM8000Base (IBASE) |
|
|
|
|
Enable ‘Enumerate in HID mode only’
Reboot needed for changing between HID and USB mode of base/reader!
DM8000Base (IBASE) |
|
|
Disable ‘Enumerate in HID mode only’
Reboot needed for changing between HID and USB mode of base/reader!
DM8000Base (IBASE) |
|
|
|
|
Enable HID mode (USB Keyboard)
No restart required, device does not lose cdc communication channel.
DM8700 |
|
|
Disable HID mode (USB Keyboard)
No restart required, device does not lose cdc communication channel.
DM8700 |
|
|
|
|
Enable HID mode (USB Keyboard)
DM8700Base |
|
|
Disable HID mode (USB Keyboard)
DM8700Base |
|
|
|
|
*Enable Base USB
Reader switches to USB when in the base.
DM8000Base (IBASE) |
|
|
Disable Base USB
Reader keeps up WiFi even when in the base.
DM8000Base (IBASE Wi-Fi) |
|
|
|
|
Enable Re-enumeration on Firmware Start
DM50 ● DM60 ● DM70 ● DM150 |
|
|
Disable Re-enumeration on Firmware Start
DM50 ● DM60 ● DM70 ● DM150 |
|
|
|
|
DTR Assertion Required for USB communication
DM8050 ● DM8700 corded
|
|
|
DTR Assertion Not Required for USB communication
DM8050 ● DM8700 corded
|
|
|
|
|
DTR Assertion Required for USB communication for Base Station
DM8700Base |
|
|
DTR Assertion Not Required for USB communication for Base Station
DM8700Base |
|
|
|
|
HID Ignore Caps Lock ON
DM8700 |
|
|
HID Ignore Caps Lock OFF
DM8700 |
|
|
|
|
Enable serial-over-USB
DM280 |
|
|
Disable serial-over-USB
DM280 |
|
