Symbology Settings
| Codes | Settings and Supported Devices | Codes |
|---|---|---|
|
|
*Enable ID Max
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8700 |
|
|
Enable ID Quick
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8700 |
|
|
|
|
*Enable Data Matrix
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Disable Data Matrix
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable QR Code
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable QR Code
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable MaxiCode
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8050 ● DM8600 ● DM8072 ● DM8700 |
|
|
*Disable MaxiCode
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8050 ● DM8600 ● DM8072 ● DM8700 |
|
|
|
|
Enable Aztec Code
DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8050 ● DM8600 ● DM8072 ● DM8700 |
|
|
*Disable Aztec Code
DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8050 ● DM8600 ● DM8072 ● DM8700 |
|
|
|
|
*Enable Code 128
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Disable Code 128
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
*Enable UPC/EAN
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Disable UPC/EAN
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
*Enable Code 39
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Disable Code 39
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
*Enable Code 93
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 ● DM8072 |
|
|
Disable Code 93
DM50 ● DM60 ● DM70 ● DM150 ● ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Interleaved 2 of 5
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 |
|
|
*Disable Interleaved 2 of 5
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
*Enable Codabar
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Disable Codabar
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Pharmacode (Not supported on DM8700)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Pharmacode
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
*Enable PDF417 (default for handheld readers)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable PDF417 (default for fixed-mount readers)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Databar (Not supported on DM8700)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Databar
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Micro PDF417 (Not supported on DM8700)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Micro PDF417
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable EAN.UCC Composite (Not supported on DM8700)
DM50 ● DM60 ● DM70 ● DM150 ● ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable EAN.UCC Composite
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable POSTNET
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable POSTNET
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable PLANET
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable PLANET
DM50 ● DM60 ● DM70 ● DM150 ●DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Japan Post
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Japan Post
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Australia Post
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Australia Post
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable UPU
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable UPU
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Enable Intelligent Mail Barcode
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable Intelligent Mail Barcode
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
