Data Validation / Data Formatting
| Codes | Settings and Supported Devices | Codes |
|---|---|---|
|
|
Enable DoD UID Validation with UII Output
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
*Disable DoD UID Validation with UII Output
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
|
|
Use Next Code As Match String (Enable Match String Validation prior to reading this code)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 ● MX-1000 ● MX-1502 |
|
|
Enable Input 1 Save Match String
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
|
|
|
|
*Disable Input 1 Save Match String
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
|
|
Enable Button Save Match String
DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
|
|
|
|
*Disable Button Save Match String
DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
