Communications
| Codes | Settings and Supported Devices | Codes |
|---|---|---|
|
|
*Enable DHCP (default for all Ethernet readers)
DM60 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000
DO NOT SCAN this code with a DM8000 wireless reader! |
|
|
Enable Multi-Port (RS-232 Sharing)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
|
|
|
|
*Disable Multi-Port (RS-232 Sharing)
DM50 ● DM60 ● DM70 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 |
|
|
Enable EtherNet/IP
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
Enable EtherNet/IP
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
*Disable EtherNet/IP
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
*Disable EtherNet/IP
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
|
Enable EtherCAT
DM280EC ● DM282EC Note: EtherCAT is enabled by default on these vision systems.
|
|
|
|
*Disable EtherCAT
DM280EC ● DM282EC |
|
|
Enable PROFINET
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
Enable PROFINET
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
*Disable PROFINET
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
*Disable PROFINET
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
Enable Modbus TCP
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
Enable Modbus TCP
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
*Disable Modbus TCP
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
*Disable Modbus TCP
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
Enable SLMP Protocol
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
Enable SLMP Protocol
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
*Disable SLMP Protocol
DM60 ● DM150 ● DM260 ● DM280 ● DM300 ● DM360 ● DM370 ● DM470 ● DM503 ● DM8000 (corded) |
|
|
|
|
*Disable SLMP Protocol
DM8000Base (IBASE BT + Wi-Fi) ● DM8700Base |
|
|
Switch to Access-Point Wi-Fi network type
You have to reboot the device after scanning this code
DM8700 Wi-Fi
|
|
