Grading Standards

For any Application Standard selected, you need to select either ISO/IEC 15415/6, or ISO/IEC 29158 (AIM DPM) grading standard depending on your application.

1D barcodes use ISO/IEC 15416.
2D barcodes printed on a label use ISO/IEC 15415.
2D DPM barcodes use ISO/IEC TR 29158, also known as AIM DPM.

Barcode Type	Marked substrate	ISO Standard
1D (Linear)	Label	ISO/IEC 15416
2D	Label	ISO/IEC 15415
Direct Part Mark (DPM)	ISO/IEC TR 29158 (also called AIM DPM)

Barcode Type

Marked substrate

ISO Standard

1D (Linear)

Label

ISO/IEC 15416

Label

ISO/IEC 15415

Direct Part Mark (DPM)

ISO/IEC TR 29158 (also called AIM DPM)

For more information, visit support.cognex.com, and navigate to Resources > Introduction to Barcode Verification.
